Two technologies sit at the core of every underground service locate: electromagnetic (EM) locating and ground penetrating radar (GPR). They’re often mentioned in the same breath, but they work in different ways, find different things, and are rarely a straight substitute for one another. Understanding the difference helps you ask the right questions before your next dig, and understand why a certified locator might reach for one, the other, or both.
How Electromagnetic Locating Works
EM locating detects conductive services, metallic pipes and cables, by tracing the electromagnetic field they generate or induce. A transmitter applies a signal to a target line (directly, by induction, or by clamping onto an exposed section), and a handheld receiver traces that signal along the service’s path on the surface. It’s fast, precise for what it’s designed to find, and the standard method for tracing live electrical cables, metallic water and gas pipes, and telecommunications conduits with a trace wire.
Its limitation is in the name: EM locating only works on conductive materials. Plastic pipes, concrete stormwater, and services without a trace wire or metallic component are effectively invisible to it.
How Ground Penetrating Radar Works
GPR takes a different approach. It sends radar pulses into the ground and reads the reflections that bounce back when the signal hits a change in material: a pipe, conduit, void, or change in soil density. Because it responds to physical contrast rather than conductivity, GPR can detect non-metallic services (PVC, concrete, fibre optic without a trace wire) that EM locating misses entirely.
The trade-off is that GPR is more sensitive to ground conditions. Dense clay, high moisture, and reinforced concrete can all reduce penetration depth and clarity, and interpreting the data takes more training than reading an EM receiver.
Key Differences at a Glance
- What it finds: EM locates conductive and metallic services; GPR detects any material with a different density to the surrounding ground, metallic or not.
- Best use case: EM for live cables and metallic pipes; GPR for plastic pipes, concrete structures, and services with no trace wire.
- Ground sensitivity: EM is largely unaffected by soil type; GPR performance varies with soil moisture, clay content, and depth.
- Typical output: EM gives a surface trace of a specific service; GPR can profile subsurface conditions more broadly, including unknown or undocumented features.
Why HCS Uses Both
Relying on a single method leaves gaps. A site with a mix of live electrical, metallic water mains, and unmarked plastic conduit needs both technologies working together to produce a complete picture, which is why HCS pairs EM locating with GPR subsurface imaging on every service locate. Cross-checking one method against the other also reduces the risk of a missed or misidentified service, particularly on sites with dense, undocumented infrastructure.
Choosing the Right Method for Your Site
In practice, you shouldn’t need to choose. A properly scoped locate will use whichever combination of EM and GPR the site demands, based on the services expected, the ground conditions, and what a BYDA enquiry has flagged as being in the area. What matters is working with a certified locator who understands the limits of each method and knows when to bring in the other.
